FEATURES & BENEFITS
• Ideal for use with electric bilge pump
• Rated to handle pumps up to 20A at 12V or 10A at 24V
• No exposed sensors eliminate corrosion possibilities
• No moving parts, totally sealed solid state electronics and field detectors
• Activates at a 41mm (1.6") fluid level and deactivates at a 9.5 mm (0.37") fluid level
• A three second delay prevents false starts from water sloshing in the bilge
• Easy to install, mounted on either horizontal or vertical surface (e.g. bulkhead or hull)
STANDARD CONFIGURATIONS
| Model Number | Voltage | Current | Wire Gauge Size /length | N.W. |
| SFBS-20-06 | 12V/24V DC | 20A at 12V or 10A at 24V | 16AWG/1000mm | 0.1KG |
.jpg)
SHIPPING INFORMATION
Selling Unit Size (L x W x H) | 4.88" x 5.15" x 2.36" (12.40 x 13.10 x 6.00 cm) |
Selling Unit Weight | 0.24 lbs (0.11 kg) |
Master Carton Size (L x W x H) | 19.88" x 15.55" x 15.94" |
Master Carton Qty | 84 pcs |
Master Carton Weight | 21.16 lbs (9.6 kg) |
Master Carton Volume | 0.081 m³ |
