MORE FEATURES & BENEFITS
• Single diaphragm pump designed
• Uses multi-positional ports for easy mounting of the pump
• Flow up to 19 lpm (5 US gpm)
• Self-priming to 3m (9.5ft), dry run capability
• Connections for 38mm (1-1/2") or 19mm (3/4") ports
• The waste pump head assembly to be rotated 360° to accommodate plumbing
• No filter required
• Double outlet valves to ensure continuous flow
STANDARD PUMP CONFIGURATIONS
| Model | Voltage | Open Flow | Max Draw(A) | Ports | Suction lift |
SFMTP1-07 | 12V | 5.0/19.0 | 8.0A | 38mm (1-1/2") or 19mm(3/4") | 3m (9.5ft) |
SFMTP2-07 | 24V | 5.0/19.0 | 2.5A | 38mm (1-1/2") or 19mm(3/4") | 3m (9.5ft) |
SHIPPING INFORMATION
Unit Weight | |
Selling Unit Size (L x W x H) | |
Selling Unit Weight | |
Master Carton Size (L x W x H) | |
Master Carton Qty | |
Master Carton Weight | |
Master Carton Volume |
